Standard Stair Lift
Alpine’s traditional value is now even better, with faster and easier installation thanks to pre-mounted 19” track section. New bolt-mounted end-cap prevents time-consuming overruns. And a host of small details, from upholstery stitching to the plastic components, add up in this Alpine upgrade, Soft Start and Soft Stop moves the rider effortlessly between levels. Alpine’s proven rack and pinion drive system continues to offer its high level of safety and dependability
Features
- Proven Rack and Pinion drive system
- Quiet Drive System with Soft Start and Stop
- DC Drive even runs during power interruptions
- Aesthetic track, finished floor mounts, and integrated charging bases
- Upholstered seat and armrest
- Folding footrest
- Includes two wireless remote controls
- Pre-mounted on 19” track section
- Service-friendly, two-piece chassis cover design
- Easy access to manual back-up
- 300 lbs. capacity
Specs
- Drive System Rack & Pinion
- Maximum Weight Capacity 300 lbs.
- Track (Rail) Type Extruded Aluminum Natural Finish
- Travel 16' Standard; 32' Maximum (9.8m)
- Average Number of Return Trips per Charge 10-20
- Lift Mounts to Steps or Wall Steps
- Minimum Folded Width 15.25" (38.7 cm)
- Electrical Requirements 100V - 240V AC
- Operation Power 24 VDC Battery/AC
- Speed 19 fpm
- Safety Devices Limit Switches, Final Limit Switch, Footrest Obstruction, Switch, Swivel Seat Cut-off, Switch, Constant Pressure, Controls, Seat Belt
- Warranty 3-Year on components, 1-Year on batteries
